Visualization of 2D Domains
This part of the visualization package is intended to supply a simple graphical interface for 2-dimensional finite element data structures. Furthermore, it is used as the low level interface for certain 3D graphics.
This graphics package uses the interface of the X11 library, no further extensions. Hence, it has been portable to any unix-like machine, including special parallel computers as GCPowerPlus. No third-party libraries are required. The look and feel of the user interface was designed to support most of the daily requirements in testing parallel algorithms. The left site shows a typical view for one example and most of the menu items that are available in the graphics window.
Note: For detailed information and helping hints click on the menu to the left.
